The solution for

• SME IT networking / computer rooms
• Control rooms
• Emergency service
• Payment systems
• Public sector
• Security control

Advantages

A flexible and cost-effective solution

• A compact range of standard product references with a variety of add-on options to adapt to every customer’s site.
• Easy to configure for retrofit in existing installations.
• Equipped with manual bypass breaker in standard mode.

Long back-up time engineered-in

• Several optimised choices for standard internal battery configuration.
• Increased internal battery density for reduced footprint and simplified installation.
• Internal basic back-up time available up 80 kVA, without additional external battery cabinet.
• High recharging current option for very long back-up time.

Embedded digital technology

• Digital Native UPS generation.
• IoT ready device for access to connected services.
• Easy integration in LAN/WAN and virtual environments.

Fast and easy installation

• A wide range of UPS from 10 to 160 kVA with the same performance and functionality.
• Free eRULER online sizing tool to get dimensions and electrical information in advance before installation.
• Tutored UPS installation with eWIRE mobile app.
• Quickly get online product documentation by simply inputting the Serial Number.

Fast delivery

• “Fast track manufacturing” option available for urgent projects or last-minute requirements.
• Fast delivery even for highly customised configurations thanks to easily combined options.

User and environmentally friendly

• 25+ languages available in the mimic panel.
• Ergonomics designed to simplify usage.
• Anticipates eco-regulations and is RoHS compliant.
• Units provided with wheels for easy positioning.

Teknik Veriler

Dosyalar

Görseller

Diğer

Teknik Veriler

Sn [kVA]	10	15	20	30	40	60	80	100	120	160
Pn [kW]	9	13.5	18	27	36	54	72	90	108	144
Input / output 3/1	•	•	•	-	-	-	-	-	-	-
Input / output 3/3	•	•	•	•	•	•	•	•	•	•
Parallel configuration	up to 6 units

Input
Rated voltage	400 V 3ph+N (3 wire input also available on demand)
Voltage tolerance	240 V to 480 V
Rated frequency	50/60 Hz ± 10%

Output
Power factor	0.9 (according to IEC / EN 62040-3)
Rated voltage	1ph + N: 230 V (can be configured 220/240 V) 3ph + N: 400 V (can be configured 380/415 V)
Rated frequency	50/60 Hz

Efficiency (TÜV SÜD verified)
Double conversion VFI mode	up to 95%
Eco Mode	up to 99%

Battery
Technologies	VRLA, NiCd
Battery configuration	internal					internal external		external

Internal back-up time (min)
Type B3	22	13	9	-
Type M3	36	22	15	-
Type M4	111	72	45	28	20	-
Type S4	-			9	6	-
Type T6	-					13	9	-

Environment
Operating ambient temperature	up to +40 °C ⁽²⁾

UPS Cabinet
Type B3 - Dimension W x D x H	370 x 770 x 1170 mm	-
Type M3 - Dimension W x D x H	370 x 770 x 1360 mm	-
Type M4 - Dimension W x D x H	444 x 800 x 1400 mm		-
Type M6 - Dimension W x D x H	-			600 x 855 x 1400 mm	-
Type T6 - Dimension W x D x H	-		600 x 855 x 1930 mm	-	600 x 855 x 1930 mm
Weight	depends on the number of batteries installed - contact us
Display	3.5”
Degree of protection	IP20 (IP21 on demand)
Colours	metallised grey E150HVR

Standards
Safety	IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2
EMC	IEC/EN 62040-2, AS 62040.2
Performance	IEC/EN 62040-3, AS 62040.3
Environmental	full compliance with the RoHS EU directive
Product declaration	CE, RCM (E2376)

Dosyalar

MASTERYS BC+ CATALOGUE-EN

MASTERYS BC+ BROCHURE-EN

Görseller

Diğer

System features

• Dual input mains (30-40 kVA).
• Internal maintenance bypass switch.
• Input mains switch breaker.
• Output switch breaker.
• Auxiliary mains switch breaker.
• Backfeed protection: detection circuit.
• Power walk-in ramp for full compatibility with generators.
• Internal normal-life batteries.

Standard communication features

• 3.5” multilanguage graphic display.
• 2 slots for communication options.
• USB port for downloading log file.
• Ethernet port for service purposes.

System options

• 3-phase input without neutral.
• Internal backfeed isolation device.
• Common mains coupling bars.
• TN-C grounding system.
• ACS synchronisation system.
• IP21 degree of protection.
• Top cabling kit.
• Top ventilation kit.
• High capacity battery charger.

Communication options

• Dry-contact interface (configurable voltage-free contacts).
• MODBUS RTU RS485 or TCP.
• PROFIBUS / PROFINET gateway.
• BACnet/IP interface.
• NET VISION: professional WEB/ SNMP Ethernet interface for secure UPS monitoring and remote automatic shutdown.
• REMOTE VIEW PRO supervision software.
• IoT Gateway for Socomec cloud services and SOLIVE UPS mobile app.
• Remote touch-screen panel.

Remote monitoring service

• LINK-UPS: Socomec 24/7 remote monitoring service connecting your installation to the nearest Socomec Service Centre.
• SOLIVE UPS: mobile app enabling the monitoring of the UPS systems from a smartphone.
